Prospect Truss Seat

Featuring striking asymmetrical forms and robust materials that are based on our competition-winning designs for the Western Sydney Parklands Trust, the Prospect truss seat is ideal for parkland and urban environments. The functional and light appearance of the truss seat features an asymmetrical steel frame that grounds the design FInishes include 5 hardwood or 5 Duraslat™ XG batten colours and 27 powder-coat finishes or a galvanised finish to suit many outdoor spaces.

Hardwood
1600mmW x 540mmD x 770mmH

Duraslat™ XG
1600mmW x 540mmD x 770mmH

Seat height: 445mm
Half back option: 1050mm long

Hardwood
Spotted Gum, Mixed Red -
Pine, Mahogany, Ebony Oil

Duraslat™ XG
Ravine, Cave, Alcove, Boulder, Dune

Hot-dip galvanised or powder-coated steel

Core
White (satin), Black (satin), Charcoal (satin), Palladium Silver (satin), Matt Black (matt), Pearl White (gloss)

Solid
Coffee (satin), Cove (satin), Monument (matt), Medium Bronze Kinetic (flat)

Textured
Core Ten (textured metallic), Asteroid (textured metallic), Bass (textured metallic), Textura Black (textured), Textura Monument (textured), Textura White (textured)

Signature
Deep Ocean (satin), Wedgewood (satin), Mangrove (satin), Territory Red (matt), Claypot (satin), Paperbark (satin)

Bold
Bondi Blue (gloss), Leaf (satin), Sensation (gloss), Lobster (satin), Moonlight (satin)

Certified Hardwood
All hardwood is sourced from sustainable forests certified by the Program for the Endorsement of Forest Certification (PEFC), the world’s largest forestry certification system.

Recycled Materials
We locally source our steel. It means we know it uses recycled content and is 100% recyclable.

Duraslat™ XG is made from 90% of recycled hardwood fibres and reclaimed plastic materials, which reduces demand for virgin materials.

Low Pollutants
Our powder-coating process doesn’t emit Volatile Organic Compounds (VOCs) and has Environmental Product Declarations (EPDs).

5-year warranty. View the warranty for more details.

6-8 weeks

Shipped fully assembled on pallets.

Surface or sub-surface fixed by others. Anchors not included.

Select your cantilever orientation
Select your backrest length
Select your batten finish
Select your frame finish

Hardwood
Cleaning
Remove any loose surface deposits with a soft bristled brush and wipe down with fresh water and a non-abrasive cloth.

Oiling
Oiling of timber will postpone natural greying, repel moisture, improve mould resistance, help maintain a smooth surface texture and enhance the grain and colour.

To maintain, lightly sand rough areas of timber and brush on one coat of timber decking oil every 6 months or as required.

Duraslat™ XG
Cleaning
Simply wash down occasionally. Do not use high pressure cleaners.

Powder-Coat
Cleaning
Carefully remove any loose surface deposits with a wet sponge or soft bristled brush.

Use a soft (non-abrasive) cloth or brush and a diluted solution of mild detergent and warm water.

Ensure surfaces are thoroughly rinsed with clean fresh water after cleaning to remove all residues.

Never use thinners, abrasive cleaning agents, alcohol-based, acid or alkali cleaning agents.

Options: left or right-hand cantilever (when seated), optional armrests, and a partial or full backrest.
